Data Sampling¶

In financial machine learning, samples are not independent. For the most part, traditional machine learning algorithms assume that samples are IID, in the case of financial machine learning samples are neither identically distributed nor independent. In this section we will tackle the problem of samples dependency.

As you will remember, we mostly label our data sets using the triple-barrier method. Each label in triple-barrier event has a label index and a label end time (t1) which corresponds to time when one of barriers were touched.

Sample Uniqueness¶

Let’s look at an example of 3 samples: A, B, C.

Imagine that:

A was generated at \(t_1\) and triggered on \(t_8\)
B was generated at \(t_3\) and triggered on \(t_6\)
C was generated on \(t_7\) and triggered on \(t_9\)

In this case we see that A used information about returns on \([t_1,t_8]\) to generate label-endtime which overlaps with \([t_3, t_6]\) which was used by B, however C didn’t use any returns information which was used by to label other samples. Here we would like to introduce the concept of concurrency.

We say that labels \(y_i\) and \(y_j\) are concurrent at \(t\) if they are a function of at least one common return at \(r_{t-1,t}\)

In terms of concurrency label C is the most ‘pure’ as it doesn’t use any piece of information from other labels, while A is the ‘dirtiest’ as it uses information from both B and C. By understanding average label uniqueness you can measure how ‘pure’ your dataset is based on concurrency of labels. We can measure average label uniqueness using get_av_uniqueness_from_triple_barrier function from the Mlfin.py package.

This function is the orchestrator to derive average sample uniqueness from a dateset labeled by the triple barrier method.

Implementation¶

mlfinpy.sampling.concurrent.get_av_uniqueness_from_triple_barrier(triple_barrier_events: DataFrame, close_series: Series, num_threads: int, verbose: bool = True) → Series[source]¶

This function is the orchestrator to derive average sample uniqueness from a dataset labeled by the triple barrier method.

Parameters¶

triple_barrier_eventspd.DataFrame: Events from labeling.get_events()
close_seriespd.Series: Close prices.
num_threadsint: The number of threads concurrently used by the function.
verbosebool: Flag to report progress on asynch jobs

Returns¶

pd.Series: Average uniqueness over event’s lifespan for each index in triple_barrier_events

Example¶

An example of calculating average uniqueness given that we have already have our barrier events can be seen below:

import pandas as pd
import numpy as np
from mlfinpy.sampling.concurrent import get_av_uniqueness_from_triple_barrier

barrier_events = pd.read_csv('FILE_PATH', index_col=0, parse_dates=[0,2])
close_prices = pd.read_csv('FILE_PATH', index_col=0, parse_dates=[0,2])

av_unique = get_av_uniqueness_from_triple_barrier(barrier_events, close_prices.close,
                                                  num_threads=3)

We would like to build our model in such a way that it takes into account label concurrency (overlapping samples). In order to do that we need to look at the bootstrapping algorithm of a Random Forest.

Sequential Bootstrapping¶

The key power of ensemble learning techniques is bagging (which is bootstrapping with replacement). The key idea behind bagging is to randomly choose samples for each decision tree. In this case trees become diverse and by averaging predictions of diverse trees built on randomly selected samples and random subset of features data scientists make the algorithm much less prone to overfit.

However, in our case we would not only like to randomly choose samples but also choose samples which are unique and non-concurrent. But how can we solve this problem? Here comes Sequential Bootstrapping algorithm.

The key idea behind Sequential Bootstrapping is to select samples in such a way that on each iteration we maximize average uniqueness of selected subsamples.

Implementation¶

The core functions behind Sequential Bootstrapping are implemented in Mlfin.py and can be seen below:

mlfinpy.sampling.bootstrapping.get_ind_matrix(samples_info_sets: Series, price_bars: DataFrame) → ndarray[source]¶

Build an Indicator Matrix

Get indicator matrix. The book implementation uses bar_index as input, however there is no explanation how to form it. We decided that using triple_barrier_events and price bars by analogy with concurrency is the best option.

Parameters¶

samples_info_setspd.Series: Triple barrier events(t1) from labeling.get_events() method.
price_barspd.DataFrame: Price bars which were used to form triple barrier events.

Returns¶

np.ndarray: Indicator binary matrix indicating what (price) bars influence the label for each observation

Notes — Reference: Advances in Financial Machine Learning, Snippet 4.3, page 65.

mlfinpy.sampling.bootstrapping.get_ind_mat_average_uniqueness(ind_mat: ndarray) → float[source]¶

Compute Average Uniqueness.

Average uniqueness from indicator matrix.

Parameters¶

ind_matnp.ndarray: Indicator binary matrix.

Returns¶

avg_uniquenessfloat: Average uniqueness.

Notes¶

Reference: Advances in Financial Machine Learning, Snippet 4.4. page 65.

mlfinpy.sampling.bootstrapping.get_ind_mat_label_uniqueness(ind_mat: ndarray) → ndarray[source]¶

Returns the indicator matrix element uniqueness.

Parameters¶

ind_matnp.ndarray: Indicator binary matrix.

Returns¶

uniquenessnp.ndarray: Label uniqueness.

— Reference: Advances in Financial Machine Learning, An adaption of Snippet 4.4. page 65.

mlfinpy.sampling.bootstrapping.seq_bootstrap(ind_mat: ~numpy.ndarray, sample_length: int | None = None, warmup_samples: ~typing.List[int] | None = None, compare: bool = False, verbose: bool = False, random_state: ~numpy.random.mtrand.RandomState = RandomState(MT19937) at 0x7F41353E3540) → List[int][source]¶

Return Sample from Sequential Bootstrap

Generate a sample via sequential bootstrap.

Parameters¶

ind_matnp.ndarray: Indicator matrix from triple barrier events.
sample_lengthOptional[int]: Length of bootstrapped sample.
warmup_samplesOptional[List[int]]: List of previously drawn samples.
comparebool: Flag to print standard bootstrap uniqueness vs sequential bootstrap uniqueness.
verbosebool: Flag to print updated probabilities on each step.
random_statenp.random.RandomState: Random state

Returns¶

phiList[int]: Bootstrapped samples indexes

Notes — Moved from pd.DataFrame to np.matrix for performance increase. Reference: Advances in Financial Machine Learning, Snippet 4.5, Snippet 4.6, page 65.

Example¶

An example of Sequential Bootstrap using a a toy example from the book can be seen below.

Consider a set of labels \(\left\{y_i\right\}_{i=0,1,2}\) where:

label \(y_0\) is a function of return \(r_{0,2}\)
label \(y_1\) is a function of return \(r_{2,3}\)
label \(y_2\) is a function of return \(r_{4,5}\)

The first thing we need to do is to build and indicator matrix. Columns of this matrix correspond to samples and rows correspond to price returns timestamps which were used during samples labelling. In our case indicator matrix is:

ind_mat = pd.DataFrame(index = range(0,6), columns=range(0,3))

ind_mat.loc[:, 0] = [1, 1, 1, 0, 0, 0]
ind_mat.loc[:, 1] = [0, 0, 1, 1, 0, 0]
ind_mat.loc[:, 2] = [0, 0, 0, 0, 1, 1]

One can use get_ind_matrix method from Mlfin.py to build indicator matrix from triple-barrier events.

triple_barrier_ind_mat = get_ind_matrix(barrier_events)

We can get average label uniqueness on indicator matrix using get_ind_mat_average_uniqueness function from Mlfin.py.

ind_mat_uniqueness = get_ind_mat_average_uniqueness(triple_barrier_ind_mat)

Let’s get the first sample average uniqueness (we need to filter out zeros to get unbiased result).

first_sample = ind_mat_uniqueness[0]
first_sample[first_sample > 0].mean()
>> 0.26886446886446885

av_unique.iloc[0]
>> tW    0.238776

As you can see it is quite close to values generated by get_av_uniqueness_from_triple_barrier function call.

Let’s move back to our example. In Sequential Bootstrapping algorithm we start with an empty array of samples (\(\phi\)) and loop through all samples to get the probability of chosing the sample based on average uniqueness of reduced indicator matrix constructed from [previously chosen columns] + sample.

phi = []
while length(phi) < number of samples to bootstrap:
    average_uniqueness_array = []
    for sample in samples:
        previous_columns  = phi
        ind_mat_reduced = ind_mat[previous_columns + i]
        average_uniqueness_array[sample] = get_ind_mat_average_uniqueness(ind_mat_reduced)

    # Normalise so that probabilities sum up to 1
    probability_array = average_uniqueness_array / sum(average_uniqueness_array)
    chosen_sample = random_choice(samples, probability = probability_array)
    phi.append(chosen_sample)

For performance increase we optimized and parallesied for-loop using numba, which corresponds to bootstrap_loop_run function.

Now let’s finish the example:

To be as close to the Mlfin.py implementation let’s convert ind_mat to numpy matrix

ind_mat = ind_mat.values

1st Iteration:

On the first step all labels will have equal probalities as average uniqueness of matrix with 1 column is 1. Say we have chosen 1 on the first step

2nd Iteration

phi = [1] # Sample chosen from the 2st step
uniqueness_array = np.array([None, None, None])
for i in range(0, 3):
    ind_mat_reduced = ind_mat[:, phi + [i]]
    label_uniqueness = get_ind_mat_average_uniqueness(ind_mat_reduced)[-1]
    # The last value corresponds to appended i
    uniqueness_array[i] = (label_uniqueness[label_uniqueness > 0].mean())
prob_array = uniqueness_array / sum(uniqueness_array)

prob_array
>> array([0.35714285714285715, 0.21428571428571427, 0.42857142857142855],
  dtype=object)

Probably the second chosen feature will be 2 (prob_array[2] = 0.42857 which is the largest probability). As you can see up till now the algorithm has chosen two the least concurrent labels (1 and 2).

3rd Iteration

phi = [1,2]
uniqueness_array = np.array([None, None, None])
for i in range(0, 3):
    ind_mat_reduced = ind_mat[:, phi + [i]]
    label_uniqueness = get_ind_mat_average_uniqueness(ind_mat_reduced)[-1]
    uniqueness_array[i] = (label_uniqueness[label_uniqueness > 0].mean())
prob_array = uniqueness_array / sum(uniqueness_array)

prob_array
>> array([0.45454545454545453, 0.2727272727272727, 0.2727272727272727],
  dtype=object)

Sequential Bootstrapping tries to minimise the probability of repeated samples so as you can see the most probable sample would be 0 with 1 and 2 already selected.

4th Iteration

phi = [1, 2, 0]
uniqueness_array = np.array([None, None, None])
for i in range(0, 3):
    ind_mat_reduced = ind_mat[:, phi + [i]]
    label_uniqueness = get_ind_mat_average_uniqueness(ind_mat_reduced)[-1]
    uniqueness_array[i] = (label_uniqueness[label_uniqueness > 0].mean())
prob_array = uniqueness_array / sum(uniqueness_array)

prob_array
>> array([0.32653061224489793, 0.3061224489795918, 0.36734693877551017],
  dtype=object)

The most probable sample would be 2 in this case.

After 4 steps of sequential bootstrapping our drawn samples are [1, 2, 0, 2].

Let’s see how this example is solved by the Mlfin.py implementation. To reproduce that:

we need to set warmup to [1], which corresponds to phi = [1] on the first step
verbose = True to print updated probabilities

samples = seq_bootstrap(ind_mat, sample_length=4, warmup_samples=[1], verbose=True)

>> [0.33333333 0.33333333 0.33333333]
>> [0.35714286 0.21428571 0.42857143]
>> [0.45454545 0.27272727 0.27272727]
>> [0.32653061 0.30612245 0.36734694]

samples
>> [1, 2, 0, 2]

As you can see the first 2 iterations of algorithm yield the same probabilities, however sometimes the algorithm randomly chooses not the 2 sample on 2nd iteration that is why further probabilities are different from the example above. However, if you repeat the process several times you’ll see that on average drawn sample equal to the one from the example

Monte-Carlo Experiment¶

Let’s see how sequential bootstrapping increases average label uniqueness on this example by generating 3 samples using sequential bootstrapping and 3 samples using standard random choise, repeat the experiment 10000 times and record corresponding label uniqueness in each experiment

standard_unq_array = np.zeros(10000) * np.nan  # Array of random sampling uniqueness
seq_unq_array = np.zeros(10000) * np.nan       # Array of Sequential Bootstapping uniqueness
for i in range(0, 10000):
    bootstrapped_samples = seq_bootstrap(ind_mat, sample_length=3)
    random_samples = np.random.choice(ind_mat.shape[1], size=3)

    random_unq = get_ind_mat_average_uniqueness(ind_mat[:, random_samples])
    random_unq_mean = random_unq[random_unq > 0].mean()

    sequential_unq = get_ind_mat_average_uniqueness(ind_mat[:, bootstrapped_samples])
    sequential_unq_mean = sequential_unq[sequential_unq > 0].mean()

    standard_unq_array[i] = random_unq_mean
    seq_unq_array[i] = sequential_unq_mean

KDE plots of label uniqueness support the fact that sequential bootstrapping gives higher average label uniqueness

We can compare average label uniqueness using sequential bootstrap vs label uniqueness using standard random sampling by setting compare parameter to True. We have massively increased the performance of Sequential Bootstrapping which was described in the book. For comparison generating 50 samples from 8000 barrier-events would take 3 days, we have reduced time to 10-12 seconds which decreases by increasing number of CPUs.

Let’s apply sequential bootstrapping to our full data set and draw 50 samples:

Standard uniqueness: 0.9465875370919882
Sequential uniqueness: 0.9913169319826338

Sometimes you would see that standard bootstrapping gives higher uniqueness, however as it was shown in Monte-Carlo example, on average Sequential Bootstrapping algorithm has higher average uniqueness.

Sample Weights¶

Mlfin.py supports two methods of applying sample weights. The first is weighting an observation based on its given return as well as average uniqueness. The second is weighting an observation based on a time decay.

By Returns and Average Uniqueness¶

The following function utilizes a samples average uniqueness and its return to compute sample weights:

mlfinpy.sample_weights.attribution.get_weights_by_return(triple_barrier_events: DataFrame, close_series: Series, num_threads: int = 5, verbose: bool = True) → Series[source]¶

Determination of Sample Weight by Absolute Return Attribution

This function is orchestrator for generating sample weights based on return using mp_pandas_obj.

Parameters¶

triple_barrier_eventspd.DataFrame: Events from labeling.get_events().
close_seriespd.Series: Close prices series.
num_threadsint, optional: The number of threads concurrently used by the function. Default is 5.
verbosebool, optional: Flag to report progress on asynch jobs. Default is True.

Returns¶

pd.Series: Sample weights based on number return and concurrency.

Notes¶

Reference: Advances in Financial Machine Learning, Snippet 4.10, page 69.

This function can be utilized as shown below assuming we have already found our barrier events

import pandas as pd
import numpy as np
from mlfinpy.sample_weights.attribution import get_weights_by_return

barrier_events = pd.read_csv('FILE_PATH', index_col=0, parse_dates=[0,2])
close_prices = pd.read_csv('FILE_PATH', index_col=0, parse_dates=[0,2])


sample_weights = get_weights_by_return(barrier_events, close_prices.close,
                                       num_threads=3)

By Time Decay¶

The following function assigns sample weights using a time decay factor

mlfinpy.sample_weights.attribution.get_weights_by_time_decay(triple_barrier_events: DataFrame, close_series: Series, num_threads: int = 5, decay: float = 1, verbose: bool = True) → Series[source]¶

Implementation of Time Decay Factors

Parameters¶

triple_barrier_eventspd.DataFrame: Events from labeling.get_events()
close_seriespd.Series: Close prices
num_threadsint: The number of threads concurrently used by the function.
decayfloat: Decay factor: - decay = 1 means there is no time decay - 0 < decay < 1 means that weights decay linearly over time, but every observation still receives a strictly positive weight, regadless of how old - decay = 0 means that weights converge linearly to zero, as they become older - decay < 0 means that the oldes portion c of the observations receive zero weight (i.e they are erased from memory)
verbosebool: Flag to report progress on asynch jobs

Returns¶

pd.Series: Sample weights based on time decay factors

Notes¶

Reference: Advances in Financial Machine Learning, Snippet 4.10, page 69.

This function can be utilized as shown below assuming we have already found our barrier events

import pandas as pd
import numpy as np
from mlfinpy.sample_weights.attribution import get_weights_by_time_decay


barrier_events = pd.read_csv('FILE_PATH', index_col=0, parse_dates=[0,2])
close_prices = pd.read_csv('FILE_PATH', index_col=0, parse_dates=[0,2])


sample_weights =  get_weights_by_time_decay(barrier_events, close_prices.close,
                                            num_threads=3, decay=0.4)
